Features
-
Generator Set
- Rating
- 1,900 ekW (2,375 kVA) Continuous
- Frequency
- 60 Hz
- Voltage
- 480 V
-
Engine
-
Dimensions
-
Standard Equipment
Engine
- G3516H, V16, 4-stroke-cycle, gas engine. Operates on 24.10 to 93.95 MJ/Nm3 (615 to 2386 btu/ft3) dry pipeline natural gas. Turbocharged Separate Circuit Aftercooled
Generator
- Double bearing SR5 1866 Frame, brushless, form wound, 12-lead design, permanent magnet excited, thouree-phase, with Cat IVR, Class H insulation operating at Class F temperature. Stator and Bearing temperature monitoring and anti-condensation space heaters
Containerized Module
- 40' ISO high cube container, 9-high stack CSC certified. Sound attenuated 79 dB(A) @ 7 m (23 ft) Sound attenuated air intake louvers and 2lockable personnel doors with panic release LH and RH engine service doors integrated intocontainer side walls 3” ANSI flange customer fuel connection
Cooling
- Standard cooling provides 40⁰C (104⁰F) ambient capability with 250mg/Nm3 NOx at 100% Continuous rating before derate, @ 500m
Generator Controls And Protection
- On Package EMCP 4.3 Control Panel System Offers engine and generator monitoring and protection, voltage regulation with Cat IVRimproves transient response performance. Controls provide auto paralleling AGC-4 controller, load sharing, VFD control, and primary generator protection for greate rversatility, package utilization and monitoring.
Modes Of Operation
- Provides for single unit stand-alone operation,island mode paralleling and load sharing withother power modules, and single unit-to-utilitymode paralleling for base load control
Lube Oil Make-up System
- Oil pan-mounted oil level regulator and 114 L (30 gal) oil tank Low level annunciation
Buy a XGC1900 Near You Today
This model is one of the many equipment options Quinn Company has in stock for your heavy equipment needs. Our knowledgeable team will help you find the right model suited for your work and deliver industry-leading support long after the sale. Take advantage of our offers and get the best solution for your business. Get a quote for a XGC1900 machine online or contact our professionals for more information about our equipment.
