Features
-
Engine
- Net Power - SAE J1349
- 70 HP (52 kW) / 86 HP (64 kW)
- Displacement
- 220 in³
- Net Power Rating at 2,200 rpm - SAE J1349
- 86 hp
- Net Power Rating at 2,200 rpm - ISO 9249
- 85 hp
- Ratings at 2,200 rpm - Gross Power SAE J1995
- 96 hp
- Power Rating Conditions - No De-Rating Required Up To
- 10,000 ft
- Engine Model
- C3.6 70 kW (96 hp) Electronic Turbo Intercooled
- Emissions
- Engine meets Tier 4 Final/Stage V emission standards.
- Net Torque Rise - 1,400 rpm - SAE J1349
- 43%
- Ratings at 2,200 rpm - Gross Power ISO 14396
- 94 hp
- Net Torque Rise - 1,400 rpm - SAE J1349
- 292 ft-lb
- Net Peak Power Rating @ 2,200 rpm - SAE J1349
- 86 hp
- Dimensions - Bore
- 3.86 in
- Net Peak Power Rating @ 2,200 rpm - ISO 9249
- 85 hp
- Dimensions - Stroke
- 4.72 in
-
Backhoe
-
Weights
-
Hydraulic System
-
Transmission
-
Sustainability
-
Axle Ratings
-
Steering
-
Service Refill Capacities
-
Standard Equipment
Standard Equipment
- Air cleaner
- Alarm, back-up
- Audible system fault alarm
- Backhoe controls, mechanical two lever
- Battery, maintenance-free, 850 CCA
- Battery disconnect switch
- Boom transport lock
- Brace, lift cylinder
- Brake, parking, mechanical
- Brakes, hydraulically boosted, oil disc, dual pedals, interlocking
- Bucket level indicator
- Canopy, ROPS/FOPS
- Coat restraint
- Coolant/antifreeze, extended life
- Counterweight, bumper
- Dome light (cab only)
- Diagnostic port for engine
- Differential lock, loader joystick
- Drink holders, two
- Engine, Cat C3.6 (Direct Injection Turbocharged), meets Tier 4 Final/Stage V emission standards, Selective Catalytic Reduction, Diesel Oxidation Catalyst (DOC)
- Engine enclosure, sound suppression, removable side panels
- Face seals, O-ring
- Fan, suction and guard
- Fast reversing shuttle, all gears
- Fenders, rear
- Filters, spin-on: fuel, engine oil, transmission oil, water separator
- Filters, bowl and cartridge: hydraulic fluid
- Flashing hazards/signal lights
- Floor mat
- Four wheel drive
- Four wheel drive shaft guard
- Fuel tank, fully enclosed
- Fully hinged front grill for cooling package cleaning access
- Gauge cluster: coolant temperature, fuel level, torque converter temperature, DEF level
- Ground level fuel fill and DEF fill
- Halogen lights, working (2 front, 2 rear)
- High ambient cooling package
- Hood lock, inside cab
- Hydraulic hose, XT™
- Hydraulic oil cooler
- Hydraulic oil level sight gauge
- Hydraulic valves, loader 2 function
- Hydraulic valves, backhoe 4 function
- Hydraulics, load sensing with variable displacement piston pump
- Indicator lights: wait to start, water in fuel, engine warning, warning lamp, emissions module malfunction, low battery/charging system warning, high hydraulic oil temperature: LCD warnings: engine oil pressure, machine locked, service due, air filter blocked, high coolant temperature, auto idle shutdown, high torque converter temperature, hydraulic filter bypass
- Instrument panel lights
- Key start/stop system
- LCD operator display with soft key controls: engine speed, hour meter, gear/direction, battery voltage, hydraulic oil temperature, torque converter temperature, coolant temperature, trip totals (fuel and hours), lifetime totals (fuel and hours), operator settings (units, brightness, programmable hoe auxiliary flow), service mode diagnostics, maintenance intervals, ECM/system info
- Loader, self-leveling, return-to-dig and transmission disconnect switch
- Loader, single tilt
- Mechanical two lever controls
- Mirror, interior, rearview
- Open circuit breather
- Power receptacle, 5 volt USB, 1 internal
- Power receptacle, 12 volt, 2 internal, 1 external
- Power steering, hydrostatic
- Product Link™, cellular, network manager
- Product Link, satellite, network manager
- Seat belt, retractable, 51 mm (2 in)
- Socket, two roof
- Stabilizer shoes, street
- Steering column, tilting
- Steering knob
- Seat, air suspension, vinyl cover, with armrest
- Starting system, glow plugs
- Storage compartment, lockable
- Storage tray
- Stop and tail lights
- Swing transport lock
- Tilt steering column
- Tires
- Toolbox, external, lockable
- Torque converter
- Throttle, hand and foot, electronic
- Transmission, four speed, manual, syncromesh
- Transmission neutralizer switch
- Transport tie-downs
- Vandalism locks, four
- Warning horn, electric
-
Optional Equipment
Optional Equipment
- Auxiliary hydraulics, rear, adjustable flow
- Battery, additional, 850 CCA
- Brake, parking, Spring Applied Hydraulically Release (SAHR)
- Cab, standard
- Cold weather fuel (–30° C/–22° F)
- Cold weather package, including additional battery, engine block heater, radiator antifreeze (–50° C/–58° F), cold weather fuel (–30° C/–22° F) and mounting for an ether bottle
- Counterweights, 115 kg (255 lb), 240 kg (530 lb) or 460 kg (1,015 lb)
- Fenders, front with integral steps
- Guard, boom protection plate
- Guard, stabilizer, rock
- Hydraulic valves, loader (3rd valve for MP or Quick Coupler)
- Hydraulic valves, backhoe (5th and 6th function)
- Hydraulic lines, combined function auxiliary
- Joystick controls: pilot operated, excavator style with pattern changer
- LED lights, working (2 front, 2 rear)
- Pattern changer, in cab
- Quick Coupler, hydraulic, dual lock
- Quick Coupler, manual, dual lock
- Quick Coupler, manual, pin lock
- Radio and CD player, Bluetooth®
- Ride Control
- Rotating beacon, magnetic mount
- Seat, air suspension, fabric with armrest
- Seat belt, retractable, 75 mm (3 in)
- Security system, Bluetooth
- Security System, operator display
- Side mirrors, cab, external
- Single Tilt Loader Coupler, Integrated Tool Carrier (IT) Interface
- Stabilizer pads, grouser type
- Stabilizer pads, reversible
- Stick, extendible
- Transmission, 4 speed, powershift
- Vandalism protection, gauge cover
- Work Tool Attachments such as buckets, forks, material handling arms, augers, hammers, brooms, cold planers and vibratory plate compactors. See your Cat dealer for more information.
Explore the Cat 416 for Sale at Quinn Company
Quinn Company is an authorized Cat 416 Backhoe Loader dealer in Southern and Central California with a large inventory of these machines. Explore our equipment selection to find the model with the specs you need for your project. Our experts are available to help you choose the right machine for your needs.
Exclusive Cat 416 Price Discounts and Savings
Quinn Company provides exclusive discounts and special offers on quality Cat machines. Working with Cat Financial, our financing options allow you to make the purchase on an installment plan, so you won’t have to pay the entire cost upfront.
About the Cat 416 Backhoe Loader's Features and Capabilities
The Cat 416 Backhoe Loader delivers an impressive lift height and reach that allows you to move virtually any material around the jobsite. The machine’s lifting performance and stability support your material handling needs. Its features include:
Buy a 416 Backhoe Loader Near You Today
This model is one of the many equipment options Quinn Company has in stock for your heavy equipment needs. Our knowledgeable team will help you find the right model suited for your work and deliver industry-leading support long after the sale. Take advantage of our offers and get the best solution for your business. Get a quote for a 416 Backhoe Loader machine online or contact our professionals for more information about our equipment.
